Open RiOMar HEALPix_Zarr data - RIOMAR

Prerequisites¶

. Install:

pip install xdggs

What this notebook does¶

Loads the Healpix_ Zarr riomar data
visualise with xdggs

Steps¶

Setup & load inputs

Load the Zarr file

**visualise **

Output dataset conventions¶

meta data shoudl be updated to aligne fair practice?

Step 1 — Setup & load zarr file¶

##on HPC
import os
import psutil
from dask.distributed import Client, LocalCluster

from pathlib import Path
import xarray as xr
import numpy as np
import xdggs
import healpix_geo


# pick a fast local path on the compute node
local_dir = (
 "/tmp"
)
local_dir = str(Path(local_dir) / "dask-scratch")
print("Using Dask local_directory:", local_dir)


print("=== Starting local Dask cluster (auto-sized) ===")

cpu = os.cpu_count() or 1
total_gb = psutil.virtual_memory().total / (1024**3)

# Good “use most, but not all” defaults:
n_workers = cpu                   # ~1 worker per CPU core
threads_per_worker = 1            # best for numpy-heavy compute
memory_limit_gb = (total_gb * 0.85) / n_workers  # leave ~15% headroom
memory_limit = f"{memory_limit_gb:.2f}GB"
n_workers=32
cluster = LocalCluster(
    n_workers=n_workers,
#    threads_per_worker=threads_per_worker,
    processes=True,
    memory_limit=memory_limit,
    local_directory=local_dir,   # <--- THIS FIXES THE WARNING
    dashboard_address=":8787",
)
client = Client(cluster)

print("Dask dashboard:", client.dashboard_link)

print("\n=== Dask cluster resources ===")
info = client.scheduler_info()
workers = info["workers"]

total_threads = sum(w["nthreads"] for w in workers.values())
total_mem_gb = sum(w["memory_limit"] for w in workers.values()) / (1024**3)

print(f"Workers: {len(workers)}")
print(f"Total threads: {total_threads}")
print(f"Total memory limit: {total_mem_gb:.2f} GB")

# Optional: per-worker details
#for addr, w in workers.items():
 #   print(f"- {addr}: nthreads={w['nthreads']}, mem_limit={w['memory_limit']/1e9:.2f} GB »)

import xarray as xr
import xdggs
from dask.distributed import Client, LocalCluster

cluster = LocalCluster()
client = Client(cluster)
client

zarr_hp_file_path = "https://data-fair2adapt.ifremer.fr/riomar-zarr_tina/small_hp.zarr"
# zarr_hp_file_path = "/scale/riomar-zarr_tina/small_hp.zarr"
# zarr_hp_file_path = "https://data-fair2adapt.ifremer.fr/riomar-zarr_tina/test3.zarr"
# zarr_hp_file_path = "./riomar-zarr_tina/test3.zarr"
zarr_hp_file_path = "./riomar-zarr_tina/Y2023.zarr"

ds = xr.open_zarr(zarr_hp_file_path)
# ds = ds.persist().sortby("time_counter")
ds

/var/folders/zf/53jxd5nj2j3dmfjqpx41p24c0000gn/T/ipykernel_43868/25675482.py:7: RuntimeWarning: Failed to open Zarr store with consolidated metadata, but successfully read with non-consolidated metadata. This is typically much slower for opening a dataset. To silence this warning, consider:
1. Consolidating metadata in this existing store with zarr.consolidate_metadata().
2. Explicitly setting consolidated=False, to avoid trying to read consolidate metadata, or
3. Explicitly setting consolidated=True, to raise an error in this case instead of falling back to try reading non-consolidated metadata.
  ds = xr.open_zarr(zarr_hp_file_path)

Step 2 -- resample the data and visualise¶

2.1 plot daily mean¶

# Make time monotonic (required for resample)

ds = ds.sortby("time_counter")
# Daily mean
ds_mean_daily = ds.resample(time_counter="1D").mean(keep_attrs=True)
ds_mean_daily

(
    ds_mean_daily.compute()
    .pipe(xdggs.decode)
    .dggs.assign_latlon_coords()
    .dggs.explore(alpha=0.3)
)

/Users/annef/mamba/envs/riomar/lib/python3.12/site-packages/jupyter_client/session.py:727: UserWarning: Message serialization failed with:
Out of range float values are not JSON compliant: nan
Supporting this message is deprecated in jupyter-client 7, please make sure your message is JSON-compliant
  content = self.pack(content)

2.2 plot time series of one point¶

chose one point and make time series plot

import healpix_geo as hpg

# 1) Midpoint of your bbox
lon_min, lon_max = -2.8, -1.97333
lat_min, lat_max = 47.04367, 47.31558

lon_mid = (lon_min + lon_max) / 2.0
lat_mid = (lat_min + lat_max) / 2.0

print("midpoint:", lon_mid, lat_mid)

# 2) Pick up the level from the dataset's cell_ids attribute
level = ds.cell_ids.attrs["level"]

# Common attribute keys people use — adjust if your file uses
# another name


print("HEALPix level:", level)

# 3) Compute the Helix cell_id for that lon/lat using healpix_geo
#    (function names vary between packages/versions)
cell_id = hpg.nested.lonlat_to_healpix(lon_mid, lat_mid, depth=level, ellipsoid="WGS84")

print("HEALPix cell_id:", cell_id)

# 4) Select that cell from ds
# If cell_ids is a coordinate along dimension "cell_ids",
# this should work:
ds_point = (
    ds.sel(cell_ids=cell_id).pipe(xdggs.decode).dggs.assign_latlon_coords().compute()
)

midpoint: -2.386665 47.179625
HEALPix level: 13
HEALPix cell_id: [225773393]

import matplotlib.pyplot as plt

ds_point.zeta.plot()

plt.savefig("zeta.png", dpi=300, bbox_inches="tight")
plt.close()
